ZEISS Mikroskop Modul for Kamera Axiocam 208 Farge incl adapter 0,5X

Microscopy camera Axiocam 208 color module incl. adapter 0.5x Consists of: - Microscopy camera Axiocam 208 color - Camera adapter 60N-C 2/3" 0.5x Technical specification Axiocam 208 color: Most versatile color camera for education, documentation and routine applications with standalone capability, USB3.0 and Ethernet co nnectivity with 64bit driver software for: ZEN (blue and core), Labscope and TWAIN plugin. Camera package contains the following accessories: - USB 3.0 hub Type-C, - USB 3.0 flash drive, Type-C and Type-A - USB 3.0 cable Type-C to Type-A - Power & signal cable camera to microscope stand compatible with Axiolab 5 and Axioscope 5/7/Vario - Power adapter with country-specific plug Sensor: Sony CMOS image sensor Color,Rolling Shutter Number of Pixel: 3840 (H) x 2160 (V) = 8.3MP, Ultra HD (4K) Selectable Resolution: 3840 x 2160 = Ultra HD (4K) and 1920 x 1080 = Full HD (1080p) Pixel size: 1.85 µm x 1.85 µm Effective Area: 7.1 mm x 4.0 mm, equivalent to 1/2.1" (8.1 mm diagonal) Spectral range: approx. 400 nm – 700 nm, IR filter; RGB Bayer color mask Control buttons on camera for stand-alone use: 1x Image capture 1x OSD (On Screen Display menu) 1x Camera factory reset Status-LED for camera: color coded operation status Stand-alone: Image storage format: TIFF or JPG Video stream format: mp4 Live frame rate via HDMI: 30 fps @ 4K/1080p (also with HDR) Live frame rate through software via Ethernet or USB 3.0 (depending on hardware and software configuration), Exp. Time 1 ms: H x V Frame rate 3840 x 2160 up to 15 fps (ZEN blue edition) 1920 x 1080 up to 27 fps (ZEN blue edition) 1920 x 1080 up to 30 fps (Labscope) Digitization: 24-bit (3 x 8-bit RGB) A/D conversion Integration time: 0.06 ms up to 1 s Gain: 1x - 22x Interfaces for Communication and for Power: HDMI for monitor USB 3.0 Type C for USB hub, flashdrive, Wi-Fi adapter or, PC connection Ethernet (RJ45) for LAN connection Micro-D for power and communication with dedicated stands Optical interface: C-mount Max. file size per image: .tiff up to: 24 MB (not content dependent) .jpg up to: approx.0.5 MB – 3.3 MB (content dependent) Size/Weight: approx. 135 x 97 x 54mm / 590 g Housing: Blue painted aluminum and cooling fins on the top plate Registration: CE, RoHS, CSA Power supply: via Micro-D interface Power consumption: 9 W (24 V DC,0.375 A) Environmental conditions: +10°C to +40°C, max. 75% relative air humidity at 35°C, no condensation, free air circulation required, indoor use Supported Operating Systems: for ZEN: Windows 10 x64 or higher for Labscope: Windows 10 x64 or higher, iOS v13 or higher, Android 9.0 or higher Supported Application Software: ZEN 3.0 (blue edition) or higher ZEN core v2.7 or higher Labscope v2.9.1 or higher (Windows), v3.0 or higher (iOS), v4.0 or higher (Android) TWAIN Plugin (Software interface to control camera by 3rd party application software) The camera is network-enabled and can be used with the ZEISS iOS App, Android APP and ZEISS Labscope software. The Apps are available as a free download from the Apple® App Store, Google Play Store or ZEISS Portal. Unless otherwise stated by the distributor, iPad® and WLAN router are Not supplied by ZEISS. Apple® and Apple iPad® are registered trademarks of Apple Inc.
